Jelly SPARQL query results format specification

This document is the specification of the Jelly SPARQL query results format, also known as Jelly-SPARQL. It is intended for implementers of Jelly libraries and applications. If you are looking for a user-friendly introduction to Jelly, see the Jelly index page.

Jelly-SPARQL is a binary serialization format for SPARQL query results – solution sequences (SELECT) and boolean results (ASK). It is binary, streamable, and reuses the RDF term encoding of Jelly-RDF.

This document is accompanied by the Jelly Protobuf reference and the Protobuf definitions themselves (sparql.proto and rdf.proto).

The following assumptions are used in this document:

Jelly-SPARQL reuses Protobuf messages and encoding rules from the Jelly RDF serialization format, version 1.2.0. Concepts, definitions, and Protobuf messages defined there apply also here, unless explicitly stated otherwise.
The basis for the terms used is the RDF 1.2 specification (W3C Candidate Recommendation Snapshot 07 April 2026). The format also supports an RDF 1.1 mode.
The basis for the terms related to query results is the SPARQL 1.2 Query Language specification (W3C Working Draft 21 September 2026), in particular the definitions of a solution, a solution sequence, and a query variable.
In parts referring to the semantics of result sets, the SPARQL 1.2 Query Results JSON Format (W3C Working Draft 13 August 2026) is used.
All strings in the serialization are assumed to be UTF-8 encoded.

Document information
Author:	Piotr Sowiński (Ostrzyciel), Anastasiya Danilenka (adanilenka)
Version:	1.0.0
Date:	October 22, 2026
Permanent URL:	`https://w3id.org/jelly/1.2.0/specification/sparql`
Document status:	Stable specification (1.0.0)
License:	CC BY 4.0

Info

The key words "MUST", "MUST NOT", "REQUIRED", "SHOULD", "SHOULD NOT", "RECOMMENDED", "MAY", and "OPTIONAL" in this document are to be interpreted as described in RFC 2119.

Note

The "Note" blocks in this document are not part of the specification, but rather provide additional information for implementers.

Note

The "Example" blocks in this document are not part of the specification, but rather provide informal examples of the serialization format.

Conformance

Implementations MAY choose to implement only a subset of the following specification. In this case, they SHOULD clearly specify which parts of the specification they implement. In the rest of this specification, the keywords "MUST", "MUST NOT", etc. refer to full (not partial) implementations.

Note

Implementations may in particular choose to not implement features that are not supported on the target platform (e.g., RDF datasets, RDF-star, generalized RDF terms, etc.).

Implementations MAY also choose to extend Jelly with additional features that SHOULD NOT interfere with the serialization being readable by implementations which follow the specification.

To claim conformance with this specification, an implementation MUST pass all applicable tests from the Jelly-SPARQL conformance test suite, and MUST provide a conformance report as described on the reporting conformance page. Implementations SHOULD pass the conformance tests marked with the SHOULD conformance level (jellyt:featureShouldLevel).

Note

Conformance tests are a way to verify that implementations correctly follow the specification. However, passing all tests does not guarantee that the implementation perfectly implements the specification, is free of bugs, or that it will work in all scenarios.

Implementations typically also employ extensive unit tests, integration tests, and other quality assurance measures to ensure correctness and reliability.

Versioning

The format follows the Semantic Versioning 2.0 scheme. Each MAJOR.MINOR semantic version corresponds to an integer version tag in the format. The version tag is encoded in the version field of the SparqlResultsOptions message. See also the section on stream options for more information on how to handle the version tags in serialized streams.

The following versions of the format are defined:

Version tag	Semantic version	Last release date	Changes
1	1.0.0	October 23, 2026	(initial version)

Jelly-SPARQL has its own version tag, which is independent of the version tags of Jelly-RDF and Jelly-Patch.

Note

Releases of the protocol are published on GitHub.

Backward compatibility

Implementations SHOULD ensure backward compatibility. To achieve backward compatibility, the implementation MUST be able to read all messages from the previous releases of the protocol with the same MAJOR version. The implementation MAY also be able to read messages from previous releases of the protocol with a different MAJOR version.

Note

The protocol is designed in such a way that you don't need to worry about backward compatibility. The only thing you need to do is to implement the latest version of the protocol, and you will automatically get backward compatibility with all previous versions (of the same MAJOR).

Forward compatibility

Forward compatibility is not guaranteed across different MINOR versions of the protocol. Implementations MAY be able to read messages from future releases of the protocol with the same MAJOR version. Implementations MAY also be able to read messages from future releases of the protocol with a different MAJOR version.

New features introduced in PATCH versions of the protocol MUST NOT break forward compatibility.

Note

See also the notes about the practical implications of this in the Jelly-RDF specification.

Actors and implementations

Jelly-SPARQL assumes there to be two actors involved in processing the stream: the producer (writer) and the consumer (reader). The producer is responsible for serializing the SPARQL query results into the Jelly-SPARQL format, and the consumer is responsible for parsing the Jelly-SPARQL format into SPARQL query results.

Implementations may include only the producer, only the consumer, or both.

Format specification

Jelly-SPARQL uses Protocol Buffers version 3 as the underlying serialization format. All implementations MUST use a compliant Protocol Buffers implementation. The Protocol Buffers schema for Jelly-SPARQL is defined in sparql.proto (source code, reference), which imports rdf.proto.

A Jelly-SPARQL result stream is an ordered sequence of result frames. The frames may be sent one-by-one using a streaming protocol (e.g., gRPC, MQTT, Kafka) or written in sequence to a byte stream (e.g., a file or socket) – see the delimited variant.

A result stream contains one or more result sets – see stream types. Each result set is one of the two kinds of SPARQL query results:

A solution sequence – an ordered sequence of solutions (rows). Each solution binds a subset of the result variables to RDF terms.
A boolean result – a single true or false value, as produced by an ASK query.

The kind of a result set is determined by the first frame of the result set: if the ask_result field is set in it, the result set is a boolean result. Otherwise, it is a solution sequence.

Within a frame, solutions are stored column-wise: one column per result variable. The columns are the same as in Jelly-RDF – see columns. Most variables in real result sets are bound to terms of a single type, so most columns are just one or two flat lists of primitives.

Note

See the Jelly-RDF specification for why Jelly uses columns.

Stream types

A result stream represents either a single result set, or a sequence of result sets. This is set by the stream_type field (2) of the stream options, a SparqlStreamType value:

SPARQL_STREAM_TYPE_FLAT (0) – default value. The entire stream is a single result set, ended by a trailer.
SPARQL_STREAM_TYPE_PUNCTUATED (1) – the stream is a sequence of result sets, each ended by a trailer.

The consumer MUST throw an error if stream_type has a value that is not listed above.

The first frame of the stream is the first frame of a result set. In a PUNCTUATED stream, every frame that directly follows a frame with a trailer is also the first frame of a result set.

The following rules apply to PUNCTUATED streams:

A result set consists of one or more consecutive frames, starting with the first frame of the result set and ending with the first frame that has a trailer.
Each result set is either a solution sequence or a boolean result, decided by its own first frame. The result sets are independent of each other: they may declare different variables. Solution sequences and boolean results may be mixed in one stream.
The lookup tables are kept from one result set to the next.
Blank node labels are scoped to a single result set.
The stream options MUST NOT be set in a frame other than the first frame of a result set. The consumer MUST throw an error otherwise.

The value of stream_type MUST be the same in all stream options of a stream. The consumer MUST throw an error otherwise.

Consumers are not required to support PUNCTUATED streams. A consumer that does not support them SHOULD throw an error when it reads the stream options.

What PUNCTUATED streams are for

Some applications produce many result sets, one after another: a continuous query that is evaluated once per window, a pub/sub topic with the answers to a stream of queries, or a file with the results of a batch of queries.

Note

Concatenating two PUNCTUATED streams gives a valid PUNCTUATED stream with the result sets of both, in order, as long as the last result set of the first stream ends with a trailer. If it does not (for example, because the producer crashed), the stream options of the second stream end up in the middle of a result set, which is not allowed.

Result frames

A result frame is a message of type SparqlResultsFrame. A frame contains a batch of rows (solutions), together with any lookup entries it needs. It is RECOMMENDED to keep the serialized size of a frame below 1 MB.

A result stream MUST contain at least one frame. An empty input (zero bytes) is not a valid result stream, and the consumer MUST throw an error if it reads one. The first frame MUST contain the stream options and either the result set header or the boolean result.

The number of rows in a frame is given by the row_count field (3). It MUST NOT be greater than 2²⁷ − 1, which is the largest number of cells the sequence layout of a column can address. The consumer MUST throw an error otherwise.

Note

In practice the row count is bounded far below 2²⁷ − 1 by the recommended frame size.

The frames of a result stream have no meaning of their own – they are purely a batching mechanism. In particular, a frame boundary on its own does not separate one result set from another – only a trailer in a PUNCTUATED stream does.

Note

Because a frame is just a batch of rows, the producer is free to choose the batch size. A good default is to size the frames in values (cells) rather than rows, since the cost of a row grows with the number of variables: 4096 values means 4096 rows of a one-variable result set, but only 204 rows of a 20-variable one.

The producer may also have to end a frame early, when the lookup tables fill up.

Ordering

Result frames MUST be processed strictly in order. Each frame MUST be processed in its entirety before the next frame is processed.

The order of rows within a frame, and the order of the frames, together define the order of the solution sequence, and the order of the result sets in a PUNCTUATED stream. Consumers MUST preserve this order.

Implementations MAY choose to adopt a non-standard solution where the order or delivery of the frames is not guaranteed. The implementation MUST clearly specify in the documentation that it uses such a non-standard solution.

Note

See also the notes about the practical implications of this in the Jelly-RDF specification.

Making frames independently decodable

As in Jelly-RDF, a producer that re-emits all the lookup entries it needs in every frame makes each frame decodable on its own. In Jelly-SPARQL, decoding a frame also needs the header of its result set.

Frame metadata

SparqlResultsFrame messages have a metadata field (15) of type map<string, bytes>. This field is OPTIONAL and does not influence the processing of the results in any manner.

The general rules for the metadata field are identical to those of the Jelly-RDF stream frame metadata. In particular, consumers SHOULD ignore unknown keys, and MUST NOT assume that the value of a key this specification does not define is a character string or valid UTF-8.

Well-known metadata keys

This specification defines the following well-known keys for the metadata field. The value of a well-known key MUST be valid UTF-8. Consumers SHOULD validate this, and SHOULD ignore the key if the value does not parse.

Key	Value
`link`	Zero or more IRIs, separated by the LF character (U+000A). Corresponds to `head.link` in the SPARQL 1.2 Query Results JSON Format and to the `<link>` elements of the XML format.

The link key describes the result set the frame belongs to as a whole, not the frame it appears in. Producers SHOULD set it only in the first frame of the result set, and consumers SHOULD apply it to the whole result set.

All other keys are implementation-defined. Future versions of this specification may define further well-known keys.

Stream options

The stream options is a message of type SparqlResultsOptions. It MUST be set in the first frame of the stream. It MAY also be set in a later frame, which resets the stream state. In a PUNCTUATED stream, it may be set again only in the first frame of a result set.

The stream options instruct the consumer on the sizes of the lookup tables needed to decode the stream, and on the version of the format used.

The stream options message contains the following fields:

stream_name (1) – name of the stream. This field is OPTIONAL and the manner in which it should be used is not defined by this specification. It MAY be used to identify the stream.
stream_type (2) – the stream type, as a SparqlStreamType value. This field is OPTIONAL and defaults to SPARQL_STREAM_TYPE_FLAT, a single result set.
rdf_version (5) – the version of RDF whose terms may occur in the stream, as an RdfVersion value. This field is OPTIONAL and defaults to RDF_VERSION_UNSPECIFIED.
max_name_table_size (9), max_prefix_table_size (10), and max_datatype_table_size (11) – maximum sizes of the lookup tables. The rules for these fields are the same as for the fields with the same names in the Jelly-RDF stream options. In particular, max_name_table_size is REQUIRED and MUST be at least 128.
version (15) – version tag of the stream. This field is REQUIRED. The rules listed in the Jelly-RDF version tag section apply, using the version tags of Jelly-SPARQL. The Jelly-RDF rule about version tags 1 and 2 does not apply.

The limits on the lookup table sizes that consumers SHOULD apply, and their RECOMMENDED defaults, are the same as in Jelly-RDF.

Repeating the stream options (stream concatenation)

This section describes FLAT streams. In a PUNCTUATED stream, the stream options may be repeated only in the first frame of a result set. There, the lookups are emptied as described below, and the new options (such as the lookup sizes and rdf_version) apply from that frame on. They MUST be valid on their own, and the consumer MAY throw an error if it does not support them. The other rules of this section do not apply to PUNCTUATED streams.

A frame other than the first one MAY contain the stream options. Doing so resets the state of the stream:

The name, prefix, and datatype lookups are emptied, and their identifier numbering restarts from 1, as in Jelly-RDF.
The result set header ceases to be in effect – the same frame MUST repeat it.
A trailer without an error, seen earlier in the stream, ceases to apply: the result set does not end there, and the rows of the following frames are added to it. A trailer with an error does not cease to apply – the result set stays incomplete.

The reset takes effect before anything else in the frame is processed. The repeated header MUST declare the same variables, with the same names, in the same order, as the header of the first frame, because a FLAT stream always describes exactly one result set. The consumer MUST throw an error otherwise.

The repeated stream options need not be identical to the previous ones, but they MUST be valid on their own. The consumer MAY throw an error if it does not support the new options.

Blank node labels are not reset – they remain scoped to the whole stream.

What this is for

This exists so that two Jelly-SPARQL files holding results of the same query can be concatenated into one valid file.

It is not a general mid-stream reconfiguration mechanism, and it is not a way for a consumer to join a stream that is already in progress. If you want frames that can be decoded independently, see the note on independently decodable frames instead.

Warning

Because blank node labels are not reset, concatenating two files that happen to use the same blank node label will merge those blank nodes into one. If that matters for your use case, rename the labels of one of the files before concatenating.

Result set header

The result set header declares the variables of the result set. It is stored in the variables field (2) of SparqlResultsFrame, as a list of strings: the names of the variables.

The header MUST be present in the first frame of a result set with a solution sequence, and in every frame that repeats the stream options, unless the frame has a boolean result. It MUST NOT be present in a frame with a boolean result, or in any other frame. The consumer MUST throw an error if a header is present in a frame that is neither the first frame of a result set nor a frame with the stream options.

The following rules apply to the variable names:

A name is given without the leading ? or $. It SHOULD conform to the VARNAME production of SPARQL 1.2. It MUST NOT be empty. Consumers MAY check this.
The variables MUST be listed in projection order, that is, in the order in which they appear in the SELECT clause of the query. Consumers MUST preserve this order.
The variable names in one header SHOULD be unique. Consumers MAY check this.

Zero-variable result sets

A result set may have no variables at all. In this case the variables field is empty, and the row_count of each frame conveys the number of empty solutions in it. Frames of such a stream contain no columns.

An empty variables field in the first frame of a result set, or in a frame with the stream options set, MUST be interpreted as declaring a zero-variable result set, unless the frame has a boolean result.

Boolean results

A boolean result (the result of an ASK query) consists of exactly one frame, with the ask_result field (8) set to a SparqlAskResult message. The SparqlAskResult message has a single field:

value (1) – the boolean value of the result. This field is OPTIONAL and defaults to false.

The following rules apply:

The ask_result field MUST NOT be set in any frame other than the first frame of a result set. The consumer SHOULD throw an error otherwise.
The frame with a boolean result MUST NOT declare any variables, MUST NOT contain any columns, and MUST have row_count equal to 0. The consumer SHOULD throw an error otherwise.
The frame with the boolean result is the only frame of its result set. In a FLAT stream, no frame may follow it. In a PUNCTUATED stream, the next frame, if any, MUST start a new result set, so the frame with the boolean result MUST then have a trailer. The consumer SHOULD throw an error otherwise.

Consequently, FLAT streams with boolean results cannot be concatenated the way solution sequences can. To send several boolean results in one stream, use a PUNCTUATED stream.

Note

The metadata and trailer fields may still be used in a frame with a boolean result.

Stream trailer

The trailer field (9) of SparqlResultsFrame contains a SparqlResultsTrailer message, which marks the end of a result set and says whether the result set is complete. The message has a single field:

error (1) – an empty string (the default value) means the result set is complete. A non-empty value is a human-readable, UTF-8 explanation of why the producer could not produce the complete result.

The following rules apply:

A producer MUST set the trailer field in the last frame of every result set, both when the result set is complete and when the producer stops because of an error it can report. The only case in which a result set ends without a trailer is when the producer cannot write one at all, for example because its process died or the connection was lost.
In a FLAT stream, a frame with a trailer MUST NOT be followed by any frame without the stream options. The consumer SHOULD throw an error otherwise. In other words: a trailer either ends the stream, or ends a segment of a concatenated stream. In a PUNCTUATED stream, the frame after a trailer starts a new result set.
A frame with a trailer MAY also contain rows, lookup entries, a header, or a boolean result. A producer that has nothing left to write MAY end a solution sequence with a frame that contains only the trailer, with row_count equal to 0. This is not possible after a frame with a boolean result, which must have the trailer itself. In a PUNCTUATED stream, a frame with only a trailer that directly follows another frame with a trailer does not end the previous result set: it is a result set of its own, with zero variables and no solutions.
If a consumer reaches the end of the stream without having seen a trailer for the last result set, it SHOULD treat that result set as truncated, and SHOULD report this to the caller. A missing trailer is not an error in the stream: the consumer MUST NOT reject the rows it has read only because the trailer is missing.
If a consumer sees a trailer with a non-empty error, it MUST treat the result set it ends as incomplete, and MUST signal an error to the caller. It MAY still hand over the rows it read before the trailer, and SHOULD include the message in the error. In a FLAT stream, this applies even if the stream options are repeated after the trailer, and the stream ends with a trailer without an error. In a PUNCTUATED stream, the error applies only to the result set it ends, and the stream may go on with the next result set.

Why a trailer

A producer that fails part-way through a query (e.g., due to a federation timeout or a broken backend) has already written some rows by the time it finds out. Without a trailer, the bytes it has written are indistinguishable from a complete, shorter result set, and a consumer would silently return wrong answers.

Note

A producer whose process dies outright cannot write a trailer at all. That is why the absence of a trailer means "likely truncated" rather than "complete".

Trailers in boolean results

A boolean result (the result of an ASK query) is a single frame, so that frame is both the first and the last frame of its result set. It therefore also contains the trailer, next to the ask_result field. The trailer works the same as in a solution sequence: an empty error means the result is complete, and a non-empty error means the consumer must treat the result as incomplete and signal an error to the caller.

Prefix, name, and datatype lookup entries

Jelly-SPARQL uses the same lookup table mechanism as Jelly-RDF to compress IRIs and datatypes, including packed lookup entries and the rule that the working set of a batch must fit in the lookup tables. All the rules specified there apply here as well, where a batch is one SparqlResultsFrame, and a statement is one row (solution).

The packed lookup entries are stored in the following fields of SparqlResultsFrame:

names (4) – entries of the name lookup.
prefixes (5) – entries of the prefix lookup.
datatypes (6) – entries of the datatype lookup.

The lookup tables are stream-scoped: their contents are kept from one frame to the next, and their identifier numbering continues across frames – also from one result set to the next in a PUNCTUATED stream.

Columns

The columns of a frame are stored in the columns field (7) of SparqlResultsFrame, each as an RdfColumn message. The i-th column contains the values of the i-th variable of the result set header, in row order. A bound cell is the value of the variable in that solution. An unbound cell means that the variable is not bound in that solution.

The columns are encoded as described in the Jelly-RDF specification: term types, sequence layout, IRIs, literals, blank nodes, and triple terms. A column may contain any type of RDF term, and any of its cells may be unbound.

Let N be the number of variables of the result set. The following rules apply:

A frame MUST contain either exactly N columns, or zero columns. The consumer MUST throw an error otherwise.
A frame that contains no columns MUST have row_count equal to 0, unless N is 0. The consumer MUST throw an error otherwise.

Blank nodes

Blank node labels are scoped to the result set. In a FLAT stream, that is the entire result stream. In a PUNCTUATED stream, it is each result set on its own. Two cells in one result set with the same label MUST be interpreted as referring to the same blank node, regardless of which frame they are in, and regardless of whether the stream options were repeated between them. Two cells with different labels MUST be interpreted as referring to different blank nodes. Two cells in different result sets of a PUNCTUATED stream MUST be interpreted as referring to different blank nodes, even if they have the same label. The same applies to the blank node labels in triple terms.

RDF version

The rdf_version field (5) of the stream options announces which RDF terms may occur in the stream. Its values and rules are the same as for the rdf_version field of Jelly-RDF. The base directions of literals and triple terms are also encoded as in Jelly-RDF.

Delimited variant of Jelly-SPARQL

Jelly-SPARQL uses the same delimited variant as Jelly-RDF, and the same rules apply: a byte stream in the delimited variant consists of a series of delimited SparqlResultsFrame messages. A producer that writes a Jelly-SPARQL stream to a file, or sends it in an HTTP message body with the application/x-jelly-sparql media type, MUST use the delimited variant.

Delimited streams and PUNCTUATED streams

The two are unrelated and work at different levels:

The delimited variant is about how the frames are separated in a byte stream. Each frame is prefixed with its length, so that a consumer reading a file or a socket knows where one frame ends and the next one starts. It is not needed with transports that send each frame as a separate message (for example gRPC, MQTT, or Kafka).
The PUNCTUATED stream type is about how the result sets are separated in a stream. Each result set ends with a trailer. It is set in the stream options and does not depend on the transport.

Internet media type and file extension

The RECOMMENDED media type for Jelly-SPARQL is application/x-jelly-sparql. The RECOMMENDED file extension is .jellys.

The same media type is used for solution sequences and for boolean results – the two are distinguished by the contents of the first frame of each result set, not by the media type. The same holds for the stream type, which is set in the stream options.

The bytes MUST be in the delimited variant.

Use with the SPARQL 1.2 Protocol

A service implementing the SPARQL 1.2 Protocol MAY offer Jelly-SPARQL as a query results format. The following applies:

Jelly-SPARQL is a results format for SELECT and ASK queries. CONSTRUCT and DESCRIBE queries return RDF graphs, and should use Jelly-RDF (application/x-jelly-rdf) instead.
A service that streams the response SHOULD flush the connection after each frame, so that the client can start processing solutions before the query has finished.
A service that fails part-way through a query MUST write a trailer with a non-empty error before closing the connection, unless it cannot write anything more. The HTTP status line has already been sent by then, so the trailer is the only place left to say what went wrong.

Note

The last point is the main practical reason for the trailer. A 200 OK response whose body stops early looks exactly like a complete, shorter result set.

Security considerations

This section is not part of the specification.

The same security considerations apply to Jelly-SPARQL as to Jelly-RDF: Protocol Buffers, overly large lookup tables, invalid lookup entry identifiers, overly large row counts, column layouts, and deeply nested triple terms.

Query results content

Jelly-SPARQL is a general serialization format for SPARQL query results, and as such may be used to transmit malicious or misleading content. Please refer to the security considerations of the SPARQL 1.2 Query Results JSON Format and to the RDF 1.2 Turtle specification.

Implementations

This section is not part of the specification.

The following implementations of Jelly-SPARQL are available:

Jelly-JVM implementation
- Implemented actors: producer, consumer
- Supported libraries: Apache Jena, RDF4J
